JDB520 thermal conductive silicone grease (heat dissipation paste)

JDB520 thermal conductive silicone grease, as a medium for heat transfer, has excellent thermal conductivity, good lubrication and electrical insulation, as well as good resistance to high and low temperatures; With low viscosity and good construction performance, this product is based on polysiloxane and supplemented with high thermal conductivity fillers. It is non-toxic, odorless, and non corrosive, meeting RoHS directives and relevant environmental requirements, and has stable chemical and physical properties.

Feedback

Feature

● Safe and environmentally friendly, RoHS compatible;

● Efficient thermal conductivity and high electrical insulation.

● Low pressure compression application, low pressure, with high compression ratio.

● Good temperature resistance, capable of automated use

Parameter

特性	單位	典型值	測試標準
顏色	/	灰色	Visual
密度	g/cc	2.80±0.2	ASTM D792
針入度	g/min	280±30	ISO9048
最小結(jié)合厚度	mm	0.1	/
耐熱範圍	℃	-50~200	/
油離度(200℃×8hr)	%	< 1.0	ASTD E595
導熱系數(shù)	W/mK	2.00±0.2	ASTM D5470
熱阻@50psi	℃-in2/W	0.02	ASTM D5470
介電擊穿強度	V AC/mil	>800	ASTM D149
體積電阻	Ω ·cm	1x1014	ASTM D257
介電常數(shù)	@1MHz	5.5	ASTM D150
儲存期限(25℃)	月	6	/

application

Widely used as a heat transfer medium for long-term protection of sensitive electrical components: between CPUs, GPUs and heat sinks, chips and chipsets, LED lighting equipment, power supplies and UPS, LCD and PDP flat panel displays, communication products, etc. This product is particularly suitable for components with high heat dissipation requirements.

Usage method

Instructions for use

● Firstly, clean the surface to be coated, then stir the thermal conductive mud evenly, and then apply it to the contact surface of the product using a spot coating method. After the operation is completed, the unused products should be sealed and stored in a timely manner. Depending on the amount used, a suitable amount of hose can be manually squeezed for use, or a dedicated extruder can be installed for extrusion.

matters needing attention

● Store in a cool, dry, and ventilated place. The thickness of adhesive application should not exceed 6mm, and avoid contact with eyes when applying adhesive;

● This product is non-toxic and non hazardous, and can be handled and transported according to general chemicals;

● After the product is opened, the shelf life for storage is 6 months;

● Please refer to the MSDS of this product before use.

Packaging specifications

● 30ml/PE pipe, 300ml/PE pipe, 1KG/PE tank.
